MOQ :
2PcsLead Time :
3-5DaysFOB :
XiamenPayment Term :
TT ,L/CGPS Linux 4G PoC Radio
LCD display long range handheld radio SIM card walkie talkie wireless intercom two way radio
Nice price 1.44 inch color screen handheld portable walkie talkie dual sim card,single standby
It has a very competitive price, and can accept packaging OEM.
Platform function: Private call, Single call, Group call
Random combination of group calls，selective call to achieve one-to -one communication
Automatic power saving mode, super long standby time, over 160 hours of standby
We are s professional supplier of wireless communication equipment ,accept small order,
one year guarantee, good quality and reasonable price.
| Hardware Technical Frequency | ||
| Model | T20 | |
| Radio structure | Srtraight panel,External Antenna,5 Press KEY | |
| Weight | 212g | |
| Size | 132*56*35mm | |
| LCD Size | 1.44 Inch | |
| Configurations | CPU | MDM 9X07 |
| RAM | 128M | |
| Storage | 256M | |
| OS | ARM Linux | |
| Language | Chinese,English | |
| Network System | Radio Method | LTE-GNSS,TD-SCDMA ,WCDMA,GSM,CDMA |
| Frequency | AS:LTE FDD:B1/B3/B5/B8 / LTE-TDD:38/39/40/41 / WCDMA:B1/B5/B8 /TD SCDMA:B34/B39 /CDMA:BCO /GSM:B3,B8 | |
| EU:LTE FDD:B1/B3/B7/B8 /B20/B28A / LTE-TDD:38/40/41 / WCDMA:B1/B8 /GSM /EDGE:B3,B8 | ||
| US:LTE FDD:B2/B4/B5/B12/B13/B14/B66/B71 WCDMA:B2/B4/B5 | ||
| AU:LTE FDD:B1/B2/B3/B4/B5/B7/B8/B28 / LTE-TDD:B40 WCDMA:B1/B2/B4/B5/B8 /GSM /EDGE:B2/B3/B5/B8 | ||
| GPS | Optional | |
| Radio interface USB/ Battery interface USB | USB | |
| SIM Type | Dual Sim Card single standby | |
| PTT Function | Communication Method | Half duplex (Implement by software) |
| Speaker Vol | Virtual Key adjustment | |
| Tx/Rx SW | Press the PTT button to talk, release PTT button to receive voice | |
| Sound I/O | Speaker | Rated output power:1W, Maximum output power:1.5W |
| Microphone | Single MIC | |
| Battery Capacity | 4000mAh | |
| Standby Time | ≥ 120Hours | |
